About Our Ductile Iron Pipe Fittings :
ISO 2531 / EN 545 / EN 598 / GB 13295
Specifications
- Mechanical Joint Fittings (MJ)
| Material |
| BODY : Ductile iron grade 500-7 / 450-12 in accordance with ISO 1083
GLAND : Ductile iron grade 500-7 / 450-12 in accordance with ISO 1083
GASKET : Rubber E.P.D.M. / NBR / SBR in accordance with EN 681.1
T BOLTS AND NUTS : Ductile iron grade 500-7 / 450-12 in accordance with ISO 1083
|
| Working Pressure |
| 40 Bar |
| Fluid Temperature |
| 0°C-50°C, excluding frost |
| Coating |
| External coatings |
Internal coatings |
| zinc + bitumen painting
liquid epoxy resin painting
epoxy applied by FBE
according to customers' requirements
|
cement mortar lining
liquid epoxy resin painting
epoxy applied by FBE
according to customers' requirements
|
| Reference Rules |
| Dimensions and testing in accordance with ISO 2531 / EN 545 |
| Use |
| For Mechanical Joint fittings, sealing is obtained by applying pressure to the
gasket by gland. MJ fittings permits significant angular deflextion both during
and after installation and can accept a light offset of the centreline
|
Note:The gaskets, bolts & nuts are supplied separately with the fittings usually.
Company Information
About SYI Group Information :
Specialist in Municipal, Drainage & Machinery Products & Services
SYI is GroupGroup Companies have served the society for over 20 years with best Municipal, Drainage and Machinery products.
···SYI Foundry
···SYI Pipeline Corporation
···SYI Industrial Casting Division
···SYI Forging Factory
···SYI Aluminum Division
SYI is the Specialist in Municipal, Drainage & Machinery Products & Services, including pipes, fititngs,couplings, valves, manhole covers, bollards, and OEM products in different materials ,sizes and technical processes. Now I invite you to visit our site www.syigroup.com.
Our aim is to provide all of our customers with VALUE of the products in stead of only low prices!
About SYI Ductile Iron Pipe Fittings :
Specialist in PIpeline and Construction Products & Services!
SYI manufactures a full range of Ductile Iron Pipe Fitting according to ISO 2531, EN 598, EN 12842, GB 13295, ANSI/AWWA C110, C153 and other major standards.
- Flanged pipe fitting
- Loosing flanged pipe fittings
- Push-in socket pipe fittings(Tyton)
- Mechanical Joint socket pipe fittings(MJ)
- Express Joint socket pipe fittings(EX)
- Fitting for PVC pipes
- Other pipeline accessories
Our Services
Manufacture Process :
Testing / According to ISO 2531, EN 545, EN598, EN12842, GB 13295, ANSI/AWWA C110, C153 Each Ladle Test
Packaging & Shipping
Certifications
More certification ... (Contact us!)
